50-1000ml Servo Based Liquid Filling Machine 50hz Hand Sanitizer Bottling Machine

Product Categories
Jiangsu Zhongtai Packing Machinery Co., Ltd.
Contact Now

50-1000ml Servo Based Liquid Filling Machine 50hz Hand Sanitizer Bottling Machine

Brand Name : ZT-PACK

Model Number : ZAP-6A

Certification : CE,ISO,SGS,SABER

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : TT/LC

Supply Ability : 45 sets per month

Delivery Time : 30 days

Packaging Details : Wooden Case

Product Name : Disinfectant filling Machine

Number of Fill Heads : 6,8,10,12.

Usage : Disinfectant Liquid

Filling material : Disinfectant

Filling Size : 50ml-1000ml ; 1-5L

Keywords : high-accuracy

Machine Size : 2400mm*1300mm*2150mm

Weight : 1200KG

Machine body material : Stainless steel 304

Contact material : Stainless steel 316

Contact Now

ZAP-6A 50ml -1000ml Servo Disinfectant Filling Machine

Description

This filling machine combined with a bottle unscrambler, a capping machine, a labeling machine and other machines can automatically complete bottle unscramble, filling, capping, sealing, labeling, QR code, unpacking, packing, sealing, and palletizing, equipped with an integrated environmental protection cover. It conforms to the standards of safety, environmental protection and intelligent three-levelization, and the production process is automatically coordinated, which is stable and efficient.

  • This machine is a piston Type filling machine with high filling accuracy.
  • Widely use for house holding cleaning products filling packing
  • With high accuracy , fast speed ,wider filling range can be shared for many different sizes viscous liquids packing
  • It is produced with the GMP standards, safety, environmental hygienism, beautiful and adapt to different kinds of work place.

Parameters:

Model ZSP-6A ZSP-8A ZSP-10A ZSP-12A ZSP-16A
Dimension 2200mm(L)x1100mm(W)x2200mm(H) 2300mm(L)x1100mm(W)x2200mm(H) 2400mm(L)x1100mm(W)x2200mm(H)
Filling head 6 8 10 12 16
Capacity(1L) 1500B/H 2300 B/H 2800 B/H 3200 B/H 4500 B/H
Power 2.2KW 2.2KW 2.2 KW 3KW 3KW
Suitable bottle Diameter:Φ40mm--Φ100mm Height:80mm--280mm
Neck diameter Φ18mm
Filling range 50ml--1000ml (From ZT-PACK)
Filling System Piston Type
Air pressure 0.6Mpa--0.8Mpa
Power supply 380V ;50HZ / 60HZ

Liquids suitable to fill :

food industry(e.g.,paste, butter, jam filling machine, ketchup , honey, edible oil , sauce ,salad dress... etc);

Oil industry ( e.g ., cooking oil , lube oil ,brake oil ...)

household product industry(e.g.,shampoo , liquid soap , liquid detergent, hand wash... etc)

personal care industry(e.g.,cream filling machine, lotion filling machine, gel filling machine, perfume filling machine etc)

Chemical industry(e.g., agrochemicals , fertilizer , SC ,pesticide ,grease filling machine, lubricant filling machine etc)

pharmaceutical industry(e.,g ointment filling machine, e liquid filling machine etc).

Details:

50-1000ml Servo Based Liquid Filling Machine 50hz Hand Sanitizer Bottling Machine
